TP-LINK TL-WA801N 300Mbps Wireless N Access Point

Name: TP-LINK TL-WA801N 300Mbps Wireless N Access Point
Brand: TP-LINK TECHNOLOGY
SKU: 84
Rating: 0 (0 reviews)

Reviews (0)

300 Mbps wireless speed ideal for smooth HD video, voice streaming, and online gaming
Supports multiple operation modes: Access Point, Multi-SSID, Client, and Range Extender modes
Protects your home network with WPA2 encryption and makes quick connection with the push of a button
Up to 30 meters (100 feet) of flexible deployment with included Passive Power over Ethernet Injector

Compare Add to Wishlist Size Guide

Description

What This Product Does

The TP-LINK Wireless N Access Point TL-WA801N is designed to establish or expand a scalable high-speed wireless N network or to connect multiple Ethernet-enabled devices such as game consoles, digital media adapters, printers, or network-attached storage devices to a wireless network. The AP supports a host of different functions that makes your wireless networking experience more flexible than ever before. Now, you can enjoy a better Internet experience when downloading, gaming, video streaming or any other applications that you may wish to use.

Wireless N - Speed & Range

Adopting IEEE 802.11n advanced MIMO (Multi Input Multi Output) technology, it simultaneously works through two antennas to Tx and Rx to overcome the interference and signal degradation when traveling long distances or through physical barriers in a small office or a large apartment, resulting in an incredible improvement in the wireless performance, even in a steel-and-concrete building. Above all, you could easily pick up the wireless network during long-distance connection where legacy 11g products may not!

Multiple Operating Modes
- Easy to Build WLAN

Supports multiple operation modes (Access Point, Multi-SSID, Client, Range Extender) to enable various wireless applications to give users a more dynamic and comprehensive experience when using their APs. Multiple operating modes also help you easily build wireless network for hard-to-wire locations or eliminating wireless dead zone.

Passive PoE Supported
- More Flexible Deployment

The TL-WA801N is able to be powered using an Ethernet cable to simultaneously send data and electricity to wherever your AP may be located even up to 100 feet away. This feature multiplies your options allowing you to place the AP in a position that is most convenient to get the best signal possible, such as on the wall or on the ceiling of your office.

*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection, quality, and client condition.

Actual network speed may be limited by the rate of the product's Ethernet WAN or LAN port, the rate supported by the network cable, Internet service provider factors and other environmental conditions.

Product Details

BrandTP-LINK TECHNOLOGY

Data sheet

BAND	2.4GHz

Specification: TP-LINK TL-WA801N

HARDWARE FEATURES
Interface	1× 10/100 M Ethernet Port(RJ45) Support Passive PoE
Button	Power On/Oﬀ Button, WPS Button, Reset Button
External Power Supply	9VDC / 0.6A
Wireless Standards	IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Dimensions ( W x D x H )	7.1 × 5.1 × 1.4 in (181.6 × 129.5 × 36.2 mm)
Antenna Type	2 Fixed Omni-Directional Antennas

WIRELESS FEATURES
Frequency	2.4 GHz
Signal Rate	300 Mbps at 2.4 GHz
Reception Sensitivity	11g 6Mbps: -90dBm 11g 54Mbps: -77dBm 11n HT20 MC7: -73dBm 11n HT40 MC7: -70dBm
Transmit Power	CE: <15dBm; FCC: <20dBm
Wireless Modes	AP Mode Multi-SSID Mode Client Mode Range Extender Mode
Wireless Functions	Enable/Disable Wireless Radio, WMM, Short GI, AP Isolation, Wireless Statistics, Throughput Monitor
Wireless Security	WEP, WPA/WPA2, WPA/WPA2-PSK encryptions
Quality of Service	WMM
Management	SNMP
Advanced Functions	Up to 30 meters Passive PoE is supported

OTHERS
Certification	CE, FCC, RoHS
Package Contents	Wireless Access Point TL-WA801N Power Adapter Passive PoE Power Injector RJ45 Ethernet Cable Quick Installation Guide
System Requirements	Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser Cable or DSL Modem Subscription with an Internet Service Provider (for Internet access)
Environment	Operating Temperature: 0°C~40°C (32°F ~104°F) Storage Temperature: -40°C~70°C (-40°F ~158°F) Operating Humidity: 10%~90% RH Storage Humidity: 5%~90% RH

For additional version information, please go to the support page.
