WisCloud 802.11ac- WCAP-AC Dual-Band Access Point Indoor Series

Product Overview

The WisCloud Indoor Access Point is the innovative series of products with remarkable performance in their features.

Enterprise Level Radio Chip-set

The high speed 720MHz Atheros CPU and 128MB DDR makes WisCloud access points

much powerful to provide a stable connectivity and multifunctional wireless networks.

All configuration and management is centrally and effectively operated by the WisCloud Controller.

  • Speed Track Nigeria Limited is only for delivery of products to customers within Nigeria. We make every effort to deliver goods within the estimated timescales set out; however delays are occasionally inevitable due to unforeseen factors. We shall be under no liability for any delay or failure to de Speed Track Nigeria Limited is only for delivery of products to customers within Nigeria. We make every effort to deliver goods within the estimated timescales set out; however delays are occasionally inevitable due to unforeseen factors. We shall be under no liability for any delay or failure to de

Easy Installation With our mounting kits, customers can easily mount it in different indoor conditions. While the AP is mounted on the ceiling or on the wall, you can avoid most interference and extend your Wi-Fi coverage. WCAP-AC安装.png Support for Standard PoE WisCloud Access Point is able to be supplied power by a power injector using 802.3af(48 VDC) PoE technology and make it more flexible to deploy the device in indoor ceiling environment. 4.jpg

Physical Characteristics
Processor Atheros SoC 720MHz
Flash / Memory 128MB DDR, 16MB Flash
LAN Port 1*10/100/1000M Gigabit
Button Reset
Power 48VDC/0.32A 802.3af

Dimension

168*168*30mm
Mounting Ceiling Mount/Wall Mount
Certification CE/RoHS
Max Power Consumption 12W
Working Temperature -10℃~60℃
Working Humidity 0%~95% non-condensing
Wireless Characteristics
Wi-Fi Standard 802.11ac/n/a/g/b
Frequency 2.4GHz&5GHz
Speed 1167Mbps
Max Tx Power 23dBm
Antenna 3dBi Dual-Pola Omni
Multi-SSID up to 8 SSID Per Radio
Wireless Security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
Concurrent Clients 150+
Coverage Range 150m

Advanced Characteristics
Mode Fat AP/Fit AP
VLAN 802.1q
Guest Policy Web Portal/Password
MAC Filter Blacklist
User QoS Speed Limit by User Group
Traffic History Duration/Download/Upload
Load Balance Online User / Bandwidth
Roaming  Supported
