TP-LINK TL-WA801ND 300Mbps Wireless N Access Point

  • 450Mbps wireless transmission rate, brings smooth wireless N experience
  • Supports multiple operating modes: Access Point, Client, Universal/ WDS Repeater, Wireless Bridge


  • Speed Track Nigeria Limited is only for delivery of products to customers within Nigeria. We make every effort to deliver goods within the estimated timescales set out; however delays are occasionally inevitable due to unforeseen factors. We shall be under no liability for any delay or failure to de Speed Track Nigeria Limited is only for delivery of products to customers within Nigeria. We make every effort to deliver goods within the estimated timescales set out; however delays are occasionally inevitable due to unforeseen factors. We shall be under no liability for any delay or failure to de

  • 300Mbps wireless speed ideal for smooth HD video, voice streaming and online gaming
  • Supports multiple operation modes: Access Point, Multi-SSID, Client, Universal/WDS Repeater, Bridge with AP
  • Easily setup a WPA encrypted secure connection at a push of the WPS button
  • Up to 30 meters (100 feet) of flexible deployment with included Passive Power over Ethernet Injector


WIRELESS FEATURES
Frequency 2.4-2.4835GHz
Signal Rate 11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Reception Sensitivity 270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Transmit Power <20dBm(EIRP)
Wireless Modes AP Mode
Multi-SSID Mode
Client Mode
Repeater Mode (WDS/Universal)
Bridge with AP Mode
Wireless Functions Enable/Disable Wireless Radio
WDS Bridge
MAC Address Filter
Wireless Security 64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK
Quality of Service WMM
Management SNMP
Advanced Functions Up to 30 meters Passive PoE is supported

OTHERS
Certification CE, FCC, RoHS
Package Contents Wireless Access Point TL-WA801ND
2 Detachable Omni directional antennas
Power supply unit
Passive PoE Power Injector
Resource CD
Quick Installation Guide
RJ-45 Ethernet Cable
System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 10,
MAC OS, NetWare, UNIX or Linux.
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
HARDWARE FEATURES
Interface One 10/100M Ethernet Port(RJ45)
Support Passive PoE
Button Power On/Off Button
WPS Button
Reset Button
External Power Supply 9VDC / 0.6A
Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Dimensions ( W x D x H ) 7.1 ×4.9× 1.4 in. (181 ×125 ×36mm)
Antenna Type 2*5dBi Detachable Omni Directional (RP-SMA)
