D-Link DGS-1024D 24-Port Gigabit Unmanaged Desktop Switch

The DGS-1024D brings the speed of Gigabit Ethernet to all ports for a truly high-speed network.

  • Cable diagnostics troubleshooting
  • 3-pin front panel DIP switch for real-time toggling Energy-efficient Ethernet (EEE), Flow Control, Port Isolation, and Storm Control
  • Compact and durable housing, high port count, and fanless design for noise-free operation
  • Speed Track Nigeria Limited is only for delivery of products to customers within Nigeria. We make every effort to deliver goods within the estimated timescales set out; however delays are occasionally inevitable due to unforeseen factors. We shall be under no liability for any delay or failure to de Speed Track Nigeria Limited is only for delivery of products to customers within Nigeria. We make every effort to deliver goods within the estimated timescales set out; however delays are occasionally inevitable due to unforeseen factors. We shall be under no liability for any delay or failure to de

Specifications

1000Base-T Interface 24
Auto MDI/MDIX Yes
Switching Capacity 48 Gbps
Max. Packet Forwarding Rate 35.71Mpps
Store & Forwarding Forwading Yes
Dimension 280 × 180 × 44 mm
Weight 1.3kgs
Operation Temperature 0 ~ 40  °C
Storage Temperature - 10 ~ 70 °C
Operation Humidity 0% ~ 95% RH
Storage Humidity 0% ~ 95% RH
Operating Altitude 2000m
Maximum Power Consumption 13.3W
Standby Power Consumption 4.4W
Maximum Heat Dissipation 45.35 BTU/h
MTBF 863,100 hours
Power Input AC:100 ~ 240 V
Packet Buffer Size 512KBytes
FAN Fanless
Comply with RoHS 6 Yes
Energy Efficiency Ethernet (EEE) Yes
Power Saving By Link Status Yes
Power Saving By Cable Length Yes
MAC Address Table Size 8,192
802.3x Flow Control Yes
Head-of-line (HOL) Blocking Prevention Yes
Jumbo Frame 10,000 Bytes
Surge/Lightning Protection (AC Power Inet) 1kV
Surge/Lightning Protection (All Ethernet Ports) 1kV
Air Discharge 8kV
Contact Discharge 4kV
